NTLGF3402PT2G دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
NTLGF3402P
|
|
حجم فایل
|
133.732
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
8
|
مشخصات فنی
-
Manufacturer:
ON Semiconductor
-
Series:
FETKY™
-
Packaging:
Tape & Reel (TR)
-
Part Status:
Active
-
FET Type:
P-Channel
-
Technology:
MOSFET (Metal Oxide)
-
Drain to Source Voltage (Vdss):
20V
-
Current - Continuous Drain (Id) @ 25°C:
2.3A (Ta)
-
Drive Voltage (Max Rds On, Min Rds On):
2.5V, 4.5V
-
Rds On (Max) @ Id, Vgs:
140mOhm @ 2.7A, 4.5V
-
Vgs(th) (Max) @ Id:
2V @ 250µA
-
Gate Charge (Qg) (Max) @ Vgs:
10nC @ 4.5V
-
Vgs (Max):
±12V
-
Input Capacitance (Ciss) (Max) @ Vds:
350pF @ 10V
-
FET Feature:
-
-
Power Dissipation (Max):
1.14W (Ta)
-
Operating Temperature:
-55°C ~ 150°C (TJ)
-
Mounting Type:
Surface Mount
-
Supplier Device Package:
6-DFN (3x3)
-
Package / Case:
6-VDFN Exposed Pad
-
Base Part Number:
NTLGF34
-
detail:
P-Channel 20V 2.3A (Ta) 1.14W (Ta) Surface Mount 6-DFN (3x3)
