دیتاشیت NTD20P06L-1G

NTD20P06L

مشخصات دیتاشیت

نام دیتاشیت NTD20P06L
حجم فایل 142.966 کیلوبایت
نوع فایل pdf
تعداد صفحات 7

دانلود دیتاشیت NTD20P06L

NTD20P06L Datasheet

مشخصات

  • Manufacturer: ON Semiconductor
  • Series: -
  • Packaging: Tube
  • Part Status: Obsolete
  • FET Type: P-Channel
  • Technology: MOSFET (Metal Oxide)
  • Drain to Source Voltage (Vdss): 60V
  • Current - Continuous Drain (Id) @ 25°C: 15.5A (Ta)
  • Drive Voltage (Max Rds On, Min Rds On): 5V
  • Rds On (Max) @ Id, Vgs: 150mOhm @ 7.5A, 5V
  • Vgs(th) (Max) @ Id: 2V @ 250µA
  • Gate Charge (Qg) (Max) @ Vgs: 26nC @ 5V
  • Vgs (Max): ±20V
  • Input Capacitance (Ciss) (Max) @ Vds: 1190pF @ 25V
  • FET Feature: -
  • Power Dissipation (Max): 65W (Tc)
  • Operating Temperature: -55°C ~ 175°C (TJ)
  • Mounting Type: Through Hole
  • Supplier Device Package: I-PAK
  • Package / Case: TO-251-3 Short Leads, IPak, TO-251AA
  • Base Part Number: NTD20
  • detail: P-Channel 60V 15.5A (Ta) 65W (Tc) Through Hole I-PAK
