NTLJD4150PTBG دیتاشیت

مشخصات دیتاشیت

مشاهده دیتاشیت NTLJD4150P	دانلود دیتاشیت

مستندات دیگری یافت نشد!

Manufacturer: ON Semiconductor
Series: -
Packaging: Tape & Reel (TR)
Part Status: Obsolete
FET Type: 2 P-Channel (Dual)
FET Feature: Logic Level Gate
Drain to Source Voltage (Vdss): 30V
Current - Continuous Drain (Id) @ 25°C: 1.8A
Rds On (Max) @ Id, Vgs: 135mOhm @ 4A, 10V
Vgs(th) (Max) @ Id: 2V @ 250µA
Gate Charge (Qg) (Max) @ Vgs: 4.5nC @ 4.5V
Input Capacitance (Ciss) (Max) @ Vds: 300pF @ 15V
Power - Max: 700mW
Operating Temperature: -55°C ~ 150°C (TJ)
Mounting Type: Surface Mount
Package / Case: 6-WDFN Exposed Pad
Supplier Device Package: 6-WDFN (2x2)
Base Part Number: NTLJD41
detail: Mosfet Array 2 P-Channel (Dual) 30V 1.8A 700mW Surface Mount 6-WDFN (2x2)
