دیتاشیت LB1846MC-AH
مشخصات دیتاشیت
| نام دیتاشیت |
LB184(6,8)M
|
| حجم فایل |
111.088
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
4
|
مشخصات
-
Manufacturer:
ON Semiconductor
-
Series:
-
-
Packaging:
Cut Tape (CT)
-
Part Status:
Obsolete
-
Output Configuration:
Half Bridge (4)
-
Applications:
DC Motors, General Purpose, Stepper Motors
-
Interface:
Logic
-
Load Type:
Inductive
-
Technology:
Bipolar
-
Rds On (Typ):
-
-
Current - Output / Channel:
800mA
-
Current - Peak Output:
-
-
Voltage - Supply:
2.5V ~ 7.5V
-
Voltage - Load:
2.5V ~ 7.5V
-
Operating Temperature:
-20°C ~ 75°C (TA)
-
Features:
-
-
Fault Protection:
Over Temperature
-
Mounting Type:
Surface Mount
-
Package / Case:
10-LSOP (0.173", 4.40mm Width)
-
Supplier Device Package:
10-MFPSK
-
Base Part Number:
LB1846
-
detail:
Half Bridge (4) Driver DC Motors, General Purpose, Stepper Motors Bipolar 10-MFPSK
