MTD6N15T4G دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
MTD6N15T4G
|
|
حجم فایل
|
128.123
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
6
|
مشخصات فنی
-
Manufacturer:
ON Semiconductor
-
Series:
-
-
Packaging:
Cut Tape (CT)
-
Part Status:
Obsolete
-
FET Type:
N-Channel
-
Technology:
MOSFET (Metal Oxide)
-
Drain to Source Voltage (Vdss):
150V
-
Current - Continuous Drain (Id) @ 25°C:
6A (Tc)
-
Drive Voltage (Max Rds On, Min Rds On):
10V
-
Rds On (Max) @ Id, Vgs:
300mOhm @ 3A, 10V
-
Vgs(th) (Max) @ Id:
4.5V @ 1mA
-
Gate Charge (Qg) (Max) @ Vgs:
30nC @ 10V
-
Vgs (Max):
±20V
-
Input Capacitance (Ciss) (Max) @ Vds:
1200pF @ 25V
-
FET Feature:
-
-
Power Dissipation (Max):
1.25W (Ta), 20W (Tc)
-
Operating Temperature:
-65°C ~ 150°C (TJ)
-
Mounting Type:
Surface Mount
-
Supplier Device Package:
DPAK
-
Package / Case:
TO-252-3, DPak (2 Leads + Tab), SC-63
-
Base Part Number:
MTD6N
-
detail:
N-Channel 150V 6A (Tc) 1.25W (Ta), 20W (Tc) Surface Mount DPAK
