NTZD3156CT2G دیتاشیت

مشخصات دیتاشیت

دانلود دیتاشیت NTZD3156C	دانلود دیتاشیت

مستندات دیگری یافت نشد!

Manufacturer: ON Semiconductor
Series: -
Packaging: Tape & Reel (TR)
Part Status: Obsolete
FET Type: N and P-Channel
FET Feature: Logic Level Gate
Drain to Source Voltage (Vdss): 20V
Current - Continuous Drain (Id) @ 25°C: 540mA, 430mA
Rds On (Max) @ Id, Vgs: 550mOhm @ 540mA, 4.5V
Vgs(th) (Max) @ Id: 1V @ 250µA
Gate Charge (Qg) (Max) @ Vgs: 2.5nC @ 4.5V
Input Capacitance (Ciss) (Max) @ Vds: 72pF @ 16V
Power - Max: 250mW
Operating Temperature: -55°C ~ 150°C (TJ)
Mounting Type: Surface Mount
Package / Case: SOT-563, SOT-666
Supplier Device Package: SOT-563
Base Part Number: NTZD3156
detail: Mosfet Array N and P-Channel 20V 540mA, 430mA 250mW Surface Mount SOT-563
