MC74LVX574MELG دیتاشیت

مشخصات دیتاشیت

مشاهده دیتاشیت MC74LVX574	دانلود دیتاشیت

مستندات دیگری یافت نشد!

Manufacturer: ON Semiconductor
Series: 74LVX
Packaging: Cut Tape (CT)
Part Status: Obsolete
Function: Standard
Type: D-Type
Output Type: Tri-State, Non-Inverted
Number of Elements: 1
Number of Bits per Element: 8
Clock Frequency: 75MHz
Max Propagation Delay @ V, Max CL: 16.7ns @ 3.3V, 50pF
Trigger Type: Positive Edge
Current - Output High, Low: 4mA, 4mA
Voltage - Supply: 2V ~ 3.6V
Current - Quiescent (Iq): 4µA
Input Capacitance: 4pF
Operating Temperature: -40°C ~ 85°C (TA)
Mounting Type: Surface Mount
Supplier Device Package: SOEIAJ-20
Package / Case: 20-SOIC (0.209", 5.30mm Width)
Base Part Number: MC74LVX574
detail: Flip Flop 1 Element D-Type 8 Bit Positive Edge 20-SOIC (0.209", 5.30mm Width)
