NTHD5904NT1G دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
NTHD5904N
|
|
حجم فایل
|
66.971
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
6
|
مشخصات فنی
-
Manufacturer:
ON Semiconductor
-
Series:
-
-
Packaging:
Cut Tape (CT)
-
Part Status:
Obsolete
-
FET Type:
N-Channel
-
Technology:
MOSFET (Metal Oxide)
-
Drain to Source Voltage (Vdss):
20V
-
Current - Continuous Drain (Id) @ 25°C:
2.5A (Ta)
-
Drive Voltage (Max Rds On, Min Rds On):
2.5V, 4.5V
-
Rds On (Max) @ Id, Vgs:
65mOhm @ 3.3A, 4.5V
-
Vgs(th) (Max) @ Id:
1.2V @ 250µA
-
Gate Charge (Qg) (Max) @ Vgs:
6nC @ 4.5V
-
Vgs (Max):
±8V
-
Input Capacitance (Ciss) (Max) @ Vds:
465pF @ 16V
-
FET Feature:
-
-
Power Dissipation (Max):
640mW (Ta)
-
Operating Temperature:
-55°C ~ 150°C (TJ)
-
Mounting Type:
Surface Mount
-
Supplier Device Package:
ChipFET™
-
Package / Case:
8-SMD, Flat Lead
-
Base Part Number:
NTHD59
-
detail:
N-Channel 20V 2.5A (Ta) 640mW (Ta) Surface Mount ChipFET™
