NTTD4401FR2G دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
NTTD4401F
|
|
حجم فایل
|
94.45
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
8
|
مشخصات فنی
-
Manufacturer:
ON Semiconductor
-
Series:
FETKY™
-
Packaging:
Cut Tape (CT)
-
Part Status:
Obsolete
-
FET Type:
P-Channel
-
Technology:
MOSFET (Metal Oxide)
-
Drain to Source Voltage (Vdss):
20V
-
Current - Continuous Drain (Id) @ 25°C:
2.4A (Ta)
-
Drive Voltage (Max Rds On, Min Rds On):
2.5V, 4.5V
-
Rds On (Max) @ Id, Vgs:
90mOhm @ 3.3A, 4.5V
-
Vgs(th) (Max) @ Id:
1.5V @ 250µA
-
Gate Charge (Qg) (Max) @ Vgs:
18nC @ 4.5V
-
Vgs (Max):
±10V
-
Input Capacitance (Ciss) (Max) @ Vds:
750pF @ 16V
-
FET Feature:
Schottky Diode (Isolated)
-
Power Dissipation (Max):
780mW (Ta)
-
Operating Temperature:
-55°C ~ 150°C (TJ)
-
Mounting Type:
Surface Mount
-
Supplier Device Package:
Micro8™
-
Package / Case:
8-TSSOP, 8-MSOP (0.118", 3.00mm Width)
-
Base Part Number:
NTTD44
-
detail:
P-Channel 20V 2.4A (Ta) 780mW (Ta) Surface Mount Micro8™
