NUF2222FCT1G دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
NUF2222FC
|
|
حجم فایل
|
51.625
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
6
|
مشخصات فنی
-
Manufacturer:
ON Semiconductor
-
Series:
-
-
Packaging:
Cut Tape (CT)
-
Part Status:
Obsolete
-
Type:
Low Pass
-
Filter Order:
2nd
-
Technology:
RC (Pi)
-
Number of Channels:
2
-
Center / Cutoff Frequency:
190MHz (Cutoff)
-
Attenuation Value:
-20dB @ 900MHz ~ 3GHz
-
Resistance - Channel (Ohms):
33
-
Values:
R = 33Ohms, C = 36pF
-
ESD Protection:
Yes
-
Operating Temperature:
-40°C ~ 85°C
-
Applications:
USB
-
Voltage - Rated:
-
-
Mounting Type:
Surface Mount
-
Package / Case:
8-WFBGA, FCBGA
-
Size / Dimension:
0.050" L x 0.078" W (1.27mm x 1.97mm)
-
Height:
0.028" (0.70mm)
-
Base Part Number:
NUF2222
-
detail:
RC (Pi) EMI Filter 2nd Order Low Pass 2 Channel R = 33Ohms, C = 36pF 8-WFBGA, FCBGA
