CM1408-08DE 数据手册
其他文档
CM1408-08DE 9 pages
技术规格
- Manufacturer: ON Semiconductor
- Series: -
- Packaging: Tape & Reel (TR)
- Part Status: Obsolete
- Type: Low Pass
- Filter Order: 2nd
- Technology: RC (Pi)
- Number of Channels: 8
- Center / Cutoff Frequency: 200MHz (Cutoff)
- Attenuation Value: -35dB @ 1GHz
- Resistance - Channel (Ohms): 100
- Values: R = 100Ohms, C = 8.5pF
- ESD Protection: Yes
- Operating Temperature: -40°C ~ 85°C
- Applications: Data Lines for Mobile Devices
- Voltage - Rated: -
- Mounting Type: Surface Mount
- Package / Case: 16-WFDFN Exposed Pad
- Size / Dimension: 0.157" L x 0.063" W (4.00mm x 1.60mm)
- Height: 0.031" (0.79mm)
- Base Part Number: CM1408
- detail: RC (Pi) EMI Filter 2nd Order Low Pass 8 Channel R = 100Ohms, C = 8.5pF 16-WFDFN Exposed Pad
