دیتاشیت CM1418-02CP
مشخصات دیتاشیت
| نام دیتاشیت |
CM1418
|
| حجم فایل |
253.035
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
6
|
مشخصات
-
Manufacturer:
ON Semiconductor
-
Series:
Praetorian™
-
Packaging:
Tape & Reel (TR)
-
Part Status:
Obsolete
-
Type:
Low Pass
-
Filter Order:
3rd
-
Technology:
LC (Pi)
-
Number of Channels:
2
-
Center / Cutoff Frequency:
22MHz (Cutoff)
-
Attenuation Value:
35dB @ 1GHz
-
Resistance - Channel (Ohms):
0.28
-
Current:
500mA
-
Values:
L = 3nH, C = 117pF
-
ESD Protection:
Yes
-
Operating Temperature:
-40°C ~ 85°C
-
Applications:
Data Lines for Mobile Devices
-
Voltage - Rated:
-
-
Mounting Type:
Surface Mount
-
Package / Case:
6-WFBGA, WLCSP
-
Size / Dimension:
0.067" L x 0.048" W (1.72mm x 1.22mm)
-
Height:
0.028" (0.70mm)
-
Base Part Number:
CM1418
-
detail:
LC (Pi) EMI Filter 3rd Order Low Pass 2 Channel L = 3nH, C = 117pF 500mA 6-WFBGA, WLCSP
