دیتاشیت SBE805-TL-E

SBE805

مشخصات دیتاشیت

نام دیتاشیت SBE805
حجم فایل 1098.722 کیلوبایت
نوع فایل pdf
تعداد صفحات 5

دانلود دیتاشیت SBE805

SBE805 Datasheet

مشخصات

  • Manufacturer: ON Semiconductor
  • Series: -
  • Packaging: Cut Tape (CT)
  • Part Status: Obsolete
  • Diode Configuration: 2 Independent
  • Diode Type: Schottky
  • Voltage - DC Reverse (Vr) (Max): 30V
  • Current - Average Rectified (Io) (per Diode): 500mA
  • Voltage - Forward (Vf) (Max) @ If: 550mV @ 500mA
  • Speed: Fast Recovery =< 500ns, > 200mA (Io)
  • Reverse Recovery Time (trr): 10ns
  • Current - Reverse Leakage @ Vr: 30µA @ 15V
  • Operating Temperature - Junction: -55°C ~ 125°C
  • Mounting Type: Surface Mount
  • Package / Case: SC-74A, SOT-753
  • Supplier Device Package: 5-CPH
  • Base Part Number: SBE805
  • detail: Diode Array 2 Independent Schottky 30V 500mA Surface Mount SC-74A, SOT-753
