CM1631-06DE Datasheet

CM1631

Datasheet specifications

Datasheet's name CM1631
File size 1521.461 KB
File type pdf
Number of pages 16

Download Datasheet CM1631

Download Datasheet

Other documentations

No other documentation was found!

Technical specifications

  • Manufacturer: ON Semiconductor
  • Series: -
  • Packaging: Tape & Reel (TR)
  • Part Status: Obsolete
  • Type: Low Pass
  • Filter Order: 2nd
  • Technology: RC (Pi)
  • Number of Channels: 6
  • Center / Cutoff Frequency: 110MHz (Cutoff)
  • Attenuation Value: 30dB @ 800MHz ~ 6GHz
  • Resistance - Channel (Ohms): 100
  • Values: R = 100Ohms, C = 15pF
  • ESD Protection: Yes
  • Operating Temperature: -40°C ~ 85°C
  • Applications: Data Lines for Mobile Devices
  • Voltage - Rated: -
  • Mounting Type: Surface Mount
  • Package / Case: 12-UFDFN Exposed Pad
  • Size / Dimension: 0.098" L x 0.053" W (2.50mm x 1.35mm)
  • Height: 0.022" (0.55mm)
  • Base Part Number: CM1631
  • detail: RC (Pi) EMI Filter 2nd Order Low Pass 6 Channel R = 100Ohms, C = 15pF 12-UFDFN Exposed Pad
