دیتاشیت CM1453-08CP
مشخصات دیتاشیت
| نام دیتاشیت |
CM1453-08CP
|
| حجم فایل |
404.199
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
12
|
مشخصات
-
Manufacturer:
ON Semiconductor
-
Series:
Praetorian®
-
Packaging:
Tape & Reel (TR)
-
Part Status:
Obsolete
-
Type:
Low Pass
-
Filter Order:
3rd
-
Technology:
LC (Pi)
-
Number of Channels:
8
-
Center / Cutoff Frequency:
300MHz (Cutoff)
-
Attenuation Value:
35dB @ 800MHz ~ 2.7GHz
-
Resistance - Channel (Ohms):
-
-
Current:
30mA
-
Values:
L = 20nH, C = 9.5pF
-
ESD Protection:
Yes
-
Operating Temperature:
-40°C ~ 85°C
-
Applications:
Data Lines for Mobile Devices
-
Voltage - Rated:
-
-
Mounting Type:
Surface Mount
-
Package / Case:
20-WFBGA, WLCSP
-
Size / Dimension:
0.129" L x 0.045" W (3.27mm x 1.14mm)
-
Height:
0.027" (0.69mm)
-
Base Part Number:
CM1453
-
detail:
LC (Pi) EMI Filter 3rd Order Low Pass 8 Channel L = 20nH, C = 9.5pF 30mA 20-WFBGA, WLCSP
