دیتاشیت LV52207XA-VH

LV52207NXA

مشخصات دیتاشیت

نام دیتاشیت LV52207NXA
حجم فایل 3751.463 کیلوبایت
نوع فایل pdf
تعداد صفحات 18

دانلود دیتاشیت LV52207NXA

LV52207NXA Datasheet

مشخصات

  • Manufacturer: ON Semiconductor
  • Series: -
  • Packaging: Tape & Reel (TR)
  • Part Status: Active
  • Type: DC DC Regulator
  • Topology: Step-Up (Boost)
  • Internal Switch(s): Yes
  • Number of Outputs: 2
  • Voltage - Supply (Min): 2.7V
  • Voltage - Supply (Max): 5.5V
  • Voltage - Output: 40V
  • Current - Output / Channel: 20mA
  • Frequency: 1.2MHz
  • Dimming: PWM
  • Applications: Backlight
  • Operating Temperature: -40°C ~ 85°C (TA)
  • Mounting Type: Surface Mount
  • Package / Case: 9-UFBGA, WLCSP
  • Supplier Device Package: 9-WLCSP (1.3x1.3)
  • Base Part Number: LV522
  • detail: LED Driver IC 2 Output DC DC Regulator Step-Up (Boost) PWM Dimming 20mA 9-WLCSP (1.3x1.3)
