دیتاشیت ATP201-TL-H

ATP201

مشخصات دیتاشیت

نام دیتاشیت ATP201
حجم فایل 346.411 کیلوبایت
نوع فایل pdf
تعداد صفحات 7

دانلود دیتاشیت ATP201

ATP201 Datasheet

مشخصات

  • Manufacturer: ON Semiconductor
  • Series: -
  • Packaging: Tape & Reel (TR)
  • Part Status: Obsolete
  • FET Type: N-Channel
  • Technology: MOSFET (Metal Oxide)
  • Drain to Source Voltage (Vdss): 30V
  • Current - Continuous Drain (Id) @ 25°C: 35A (Ta)
  • Drive Voltage (Max Rds On, Min Rds On): 4.5V, 10V
  • Rds On (Max) @ Id, Vgs: 17mOhm @ 18A, 10V
  • Vgs(th) (Max) @ Id: -
  • Gate Charge (Qg) (Max) @ Vgs: 17nC @ 10V
  • Vgs (Max): ±20V
  • Input Capacitance (Ciss) (Max) @ Vds: 985pF @ 10V
  • FET Feature: -
  • Power Dissipation (Max): 30W (Tc)
  • Operating Temperature: 150°C (TJ)
  • Mounting Type: Surface Mount
  • Supplier Device Package: ATPAK
  • Package / Case: ATPAK (2 leads+tab)
  • Base Part Number: ATP201
  • detail: N-Channel 30V 35A (Ta) 30W (Tc) Surface Mount ATPAK
