LA5756-MDB-E 数据手册
其他文档
未找到其他文档！
技术规格
- Manufacturer: ON Semiconductor
- Series: -
- Packaging: Tube
- Part Status: Obsolete
- Function: Step-Down
- Output Configuration: Positive
- Topology: Buck
- Output Type: Adjustable
- Number of Outputs: 1
- Voltage - Input (Min): 4.5V
- Voltage - Input (Max): 32V
- Voltage - Output (Min/Fixed): 1.26V
- Voltage - Output (Max): 32V
- Current - Output: 4.2A (Switch)
- Frequency - Switching: 80kHz
- Synchronous Rectifier: No
- Operating Temperature: -30°C ~ 125°C (TJ)
- Mounting Type: Through Hole
- Package / Case: TO-220-5 Formed Leads
- Supplier Device Package: 220-5HMDB
- Base Part Number: LA5756
- detail: Buck Switching Regulator IC Positive Adjustable 1.26V 1 Output 4.2A (Switch) TO-220-5 Formed Leads
