دیتاشیت LV5072M-TLM-H
مشخصات دیتاشیت
| نام دیتاشیت |
LV5072M
|
| حجم فایل |
216.641
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
9
|
مشخصات
-
Manufacturer:
ON Semiconductor
-
Series:
-
-
Packaging:
Tape & Reel (TR)
-
Part Status:
Obsolete
-
Function:
Step-Down
-
Output Configuration:
Positive
-
Topology:
Buck
-
Output Type:
Adjustable
-
Number of Outputs:
1
-
Voltage - Input (Min):
2.95V
-
Voltage - Input (Max):
5.5V
-
Voltage - Output (Min/Fixed):
0.8V
-
Voltage - Output (Max):
3.3V
-
Current - Output:
2A
-
Frequency - Switching:
2.2MHz
-
Synchronous Rectifier:
Yes
-
Operating Temperature:
-20°C ~ 85°C (TA)
-
Mounting Type:
Surface Mount
-
Package / Case:
12-LSOP (0.173", 4.40mm Width) Exposed Pad
-
Supplier Device Package:
12-MFPS
-
Base Part Number:
LV507
-
detail:
Buck Switching Regulator IC Positive Adjustable 0.8V 1 Output 2A 12-LSOP (0.173", 4.40mm Width) Exposed Pad
