NCP706AMX300TAG دیتاشیت

مشخصات دیتاشیت

مشاهده دیتاشیت NCP706AMX300TAG	دانلود دیتاشیت

NCP706A 9 pages

RoHS: true
Category: Power Supply Chip/Linear Voltage Regulators (LDO)
Datasheet: onsemi NCP706AMX300TAG
Output Type: Fixed
Output Current: 1A
Output Voltage: 3V~3V
Dropout Voltage: 230mV@(1A)
Output Polarity: Positive
Number of Outputs: 1
Maximum Input Voltage: 5.5V
Power Supply Rejection Ratio (PSRR): 65dB@(100Hz),52dB(@10kHz)
Package: DFN-8-EP(1.2x1.6)
Manufacturer: onsemi
Series: -
Packaging: Cut Tape (CT)
Part Status: Obsolete
Output Configuration: Positive
Number of Regulators: 1
Voltage - Input (Max): 5.5V
Voltage - Output (Min/Fixed): 3V
Voltage - Output (Max): -
Voltage Dropout (Max): 0.23V @ 1A
Current - Output: 1A
Current - Quiescent (Iq): 230µA
PSRR: 65dB ~ 52dB (100Hz ~ 10kHz)
Control Features: Enable
Protection Features: Over Current, Over Temperature, Soft Start, Under Voltage Lockout (UVLO)
Operating Temperature: -40°C ~ 125°C
Mounting Type: Surface Mount
Package / Case: 8-XFDFN Exposed Pad
Supplier Device Package: 8-XDFN (1.6x1.2)
Base Part Number: NCP706
detail: Linear Voltage Regulator IC 1 Output 1A 8-XDFN (1.6x1.2)
