دیتاشیت BFL4007
مشخصات دیتاشیت
| نام دیتاشیت |
BFL4007
|
| حجم فایل |
256.748
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
6
|
مشخصات
-
Manufacturer:
ON Semiconductor
-
Series:
-
-
Packaging:
Bulk
-
Part Status:
Obsolete
-
FET Type:
N-Channel
-
Technology:
MOSFET (Metal Oxide)
-
Drain to Source Voltage (Vdss):
600V
-
Current - Continuous Drain (Id) @ 25°C:
8.7A (Ta)
-
Drive Voltage (Max Rds On, Min Rds On):
10V
-
Rds On (Max) @ Id, Vgs:
680mOhm @ 7A, 10V
-
Vgs(th) (Max) @ Id:
5V @ 1mA
-
Gate Charge (Qg) (Max) @ Vgs:
46nC @ 10V
-
Vgs (Max):
±30V
-
Input Capacitance (Ciss) (Max) @ Vds:
1200pF @ 30V
-
FET Feature:
-
-
Power Dissipation (Max):
2W (Ta), 40W (Tc)
-
Operating Temperature:
-55°C ~ 150°C (TJ)
-
Mounting Type:
Through Hole
-
Supplier Device Package:
TO-220FI(LS)
-
Package / Case:
TO-220-3 Full Pack
-
Base Part Number:
BFL40
-
detail:
N-Channel 600V 8.7A (Ta) 2W (Ta), 40W (Tc) Through Hole TO-220FI(LS)
