CM1233-08DE 数据手册
其他文档
未找到其他文档！
技术规格
- Manufacturer: ON Semiconductor
- Series: -
- Packaging: Cut Tape (CT)
- Part Status: Obsolete
- Type: Steering (Rail to Rail)
- Unidirectional Channels: 4
- Voltage - Reverse Standoff (Typ): 5.5V (Max)
- Voltage - Breakdown (Min): 6V
- Voltage - Clamping (Max) @ Ipp: 10V (Typ)
- Current - Peak Pulse (10/1000µs): 1A (8/20µs)
- Power - Peak Pulse: -
- Power Line Protection: Yes
- Applications: General Purpose
- Capacitance @ Frequency: -
- Operating Temperature: -40°C ~ 85°C (TA)
- Mounting Type: Surface Mount
- Package / Case: 16-WDFN Exposed Pad
- Supplier Device Package: 16-WDFN (6x4)
- Base Part Number: CM1233
- detail: 10V (Typ) Clamp 1A (8/20µs) Ipp Tvs Diode Surface Mount 16-WDFN (6x4)
