دیتاشیت LB11683H-MPB-E

LB11683H

مشخصات دیتاشیت

نام دیتاشیت LB11683H
حجم فایل 91.923 کیلوبایت
نوع فایل pdf
تعداد صفحات 7

دانلود دیتاشیت LB11683H

LB11683H Datasheet

مشخصات

  • Manufacturer: ON Semiconductor
  • Series: -
  • Packaging: Tape & Box (TB)
  • Part Status: Obsolete
  • Motor Type - Stepper: -
  • Motor Type - AC, DC: Brushless DC (BLDC)
  • Function: Driver - Fully Integrated, Control and Power Stage
  • Output Configuration: Half Bridge (3)
  • Interface: Parallel
  • Technology: Bipolar
  • Step Resolution: -
  • Applications: General Purpose
  • Current - Output: 1.5A
  • Voltage - Supply: 5.5V ~ 13.8V
  • Voltage - Load: 5.5V ~ 13.8V
  • Operating Temperature: -30°C ~ 85°C (TA)
  • Mounting Type: Surface Mount
  • Package / Case: 28-SOP (0.311", 7.90mm Width) Exposed Pad + 2 Heat Tabs
  • Supplier Device Package: 28-HSOP-HC
  • Base Part Number: LB1168
  • detail: Motor Driver Bipolar Parallel 28-HSOP-HC
