دیتاشیت LV8548MC-BH

مشخصات دیتاشیت

دانلود دیتاشیت LV8548MC Datasheet	LV8548MC Datasheet Datasheet

Manufacturer: ON Semiconductor
Series: -
Packaging: Cut Tape (CT)
Part Status: Obsolete
Output Configuration: Half Bridge (4)
Applications: DC Motors, General Purpose, Stepper Motors
Interface: Logic
Load Type: Inductive
Technology: DMOS
Rds On (Typ): 1Ohm
Current - Output / Channel: 1A
Current - Peak Output: -
Voltage - Supply: 4V ~ 16V
Voltage - Load: 4V ~ 16V
Operating Temperature: -30°C ~ 85°C (TA)
Features: -
Fault Protection: -
Mounting Type: Surface Mount
Package / Case: 10-SOP (0.154", 3.90mm Width)
Supplier Device Package: 10-SOIC
Base Part Number: LV854
detail: Half Bridge (4) Driver DC Motors, General Purpose, Stepper Motors DMOS 10-SOIC
