دیتاشیت BFL4007-1E

BFL4007

مشخصات دیتاشیت

نام دیتاشیت BFL4007
حجم فایل 256.748 کیلوبایت
نوع فایل pdf
تعداد صفحات 6

دانلود دیتاشیت BFL4007

BFL4007 Datasheet

مشخصات

  • Manufacturer: ON Semiconductor
  • Series: -
  • Packaging: Tube
  • Part Status: Obsolete
  • FET Type: N-Channel
  • Technology: MOSFET (Metal Oxide)
  • Drain to Source Voltage (Vdss): 600V
  • Current - Continuous Drain (Id) @ 25°C: 8.7A (Tc)
  • Drive Voltage (Max Rds On, Min Rds On): 10V
  • Rds On (Max) @ Id, Vgs: 680mOhm @ 7A, 10V
  • Vgs(th) (Max) @ Id: -
  • Gate Charge (Qg) (Max) @ Vgs: 46nC @ 10V
  • Vgs (Max): ±30V
  • Input Capacitance (Ciss) (Max) @ Vds: 1200pF @ 30V
  • FET Feature: -
  • Power Dissipation (Max): 2W (Ta), 40W (Tc)
  • Operating Temperature: -55°C ~ 150°C (TJ)
  • Mounting Type: Through Hole
  • Supplier Device Package: TO-220F-3FS
  • Package / Case: TO-220-3 Full Pack
  • Base Part Number: BFL40
  • detail: N-Channel 600V 8.7A (Tc) 2W (Ta), 40W (Tc) Through Hole TO-220F-3FS
