NCP729FC28T2G دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
NCP729
|
|
حجم فایل
|
693.756
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
13
|
مشخصات فنی
-
Manufacturer:
ON Semiconductor
-
Series:
-
-
Packaging:
Tape & Reel (TR)
-
Part Status:
Obsolete
-
Output Configuration:
Positive
-
Output Type:
Fixed
-
Number of Regulators:
1
-
Voltage - Input (Max):
5.5V
-
Voltage - Output (Min/Fixed):
2.8V
-
Voltage - Output (Max):
-
-
Voltage Dropout (Max):
0.12V @ 200mA
-
Current - Output:
200mA
-
Current - Quiescent (Iq):
50µA
-
Current - Supply (Max):
200µA
-
PSRR:
74dB (56dB (100Hz ~ 10kHz)
-
Control Features:
Enable
-
Protection Features:
Over Current, Over Temperature, Under Voltage Lockout (UVLO)
-
Operating Temperature:
-40°C ~ 125°C
-
Mounting Type:
Surface Mount
-
Package / Case:
4-WFBGA, CSPBGA
-
Supplier Device Package:
4-CSP (1.06x1.06)
-
Base Part Number:
NCP729
-
detail:
Linear Voltage Regulator IC 1 Output 200mA 4-CSP (1.06x1.06)
