دیتاشیت 2SC5415AF-TD-E
مشخصات دیتاشیت
نام دیتاشیت |
2SC5415A
|
حجم فایل |
296.878
کیلوبایت
|
نوع فایل |
pdf
|
تعداد صفحات |
8
|
مشخصات
-
Manufacturer:
ON Semiconductor
-
Series:
-
-
Packaging:
Tape & Reel (TR)
-
Part Status:
Active
-
Transistor Type:
NPN
-
Voltage - Collector Emitter Breakdown (Max):
12V
-
Frequency - Transition:
6.7GHz
-
Noise Figure (dB Typ @ f):
1.1dB @ 1GHz
-
Gain:
9dB
-
Power - Max:
800mW
-
DC Current Gain (hFE) (Min) @ Ic, Vce:
90 @ 30mA, 5V
-
Current - Collector (Ic) (Max):
100mA
-
Operating Temperature:
150°C (TJ)
-
Mounting Type:
Surface Mount
-
Package / Case:
TO-243AA
-
Supplier Device Package:
PCP
-
Base Part Number:
2SC5415
-
detail:
RF Transistor NPN 12V 100mA 6.7GHz 800mW Surface Mount PCP
