دیتاشیت 2SK4124-1E

2SK4124

مشخصات دیتاشیت

نام دیتاشیت 2SK4124
حجم فایل 281.593 کیلوبایت
نوع فایل pdf
تعداد صفحات 7

دانلود دیتاشیت 2SK4124

2SK4124 Datasheet

مشخصات

  • Manufacturer: ON Semiconductor
  • Series: -
  • Packaging: Tube
  • Part Status: Obsolete
  • FET Type: N-Channel
  • Technology: MOSFET (Metal Oxide)
  • Drain to Source Voltage (Vdss): 500V
  • Current - Continuous Drain (Id) @ 25°C: 20A (Ta)
  • Drive Voltage (Max Rds On, Min Rds On): 10V
  • Rds On (Max) @ Id, Vgs: 430mOhm @ 8A, 10V
  • Vgs(th) (Max) @ Id: -
  • Gate Charge (Qg) (Max) @ Vgs: 46.6nC @ 10V
  • Vgs (Max): ±30V
  • Input Capacitance (Ciss) (Max) @ Vds: 1200pF @ 30V
  • FET Feature: -
  • Power Dissipation (Max): 2.5W (Ta), 170W (Tc)
  • Operating Temperature: 150°C (TJ)
  • Mounting Type: Through Hole
  • Supplier Device Package: TO-3P-3L
  • Package / Case: TO-3P-3, SC-65-3
  • Base Part Number: 2SK4124
  • detail: N-Channel 500V 20A (Ta) 2.5W (Ta), 170W (Tc) Through Hole TO-3P-3L
