دیتاشیت FW276-TL-2H
مشخصات دیتاشیت
| نام دیتاشیت |
FW276
|
| حجم فایل |
433.229
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
6
|
مشخصات
-
Manufacturer:
ON Semiconductor
-
Series:
-
-
Packaging:
Cut Tape (CT)
-
Part Status:
Obsolete
-
FET Type:
2 N-Channel (Dual)
-
FET Feature:
Logic Level Gate
-
Drain to Source Voltage (Vdss):
450V
-
Current - Continuous Drain (Id) @ 25°C:
700mA
-
Rds On (Max) @ Id, Vgs:
12.1Ohm @ 350mA, 10V
-
Vgs(th) (Max) @ Id:
4.5V @ 1mA
-
Gate Charge (Qg) (Max) @ Vgs:
3.7nC @ 10V
-
Input Capacitance (Ciss) (Max) @ Vds:
55pF @ 20V
-
Power - Max:
1.6W
-
Operating Temperature:
150°C (TJ)
-
Mounting Type:
Surface Mount
-
Package / Case:
8-SOIC (0.154", 3.90mm Width)
-
Supplier Device Package:
8-SOIC
-
Base Part Number:
FW276
-
detail:
Mosfet Array 2 N-Channel (Dual) 450V 700mA 1.6W Surface Mount 8-SOIC
