دیتاشیت LV8824QA-2H
مشخصات دیتاشیت
| نام دیتاشیت | LV8824QA Datasheet |
|---|---|
| حجم فایل | 925.073 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 13 |
دانلود دیتاشیت LV8824QA Datasheet |
LV8824QA Datasheet Datasheet |
|---|
مشخصات
- Manufacturer: ON Semiconductor
- Series: -
- Packaging: Tray
- Part Status: Obsolete
- Motor Type - Stepper: -
- Motor Type - AC, DC: Brushless DC (BLDC)
- Function: Controller - Commutation, Direction Management
- Output Configuration: Pre-Driver - Half Bridge (3)
- Interface: Parallel, PWM
- Technology: Bi-CMOS
- Step Resolution: -
- Applications: General Purpose
- Current - Output: 50mA
- Voltage - Supply: 7V ~ 33V
- Voltage - Load: -
- Operating Temperature: -40°C ~ 105°C (TA)
- Mounting Type: Surface Mount
- Package / Case: 32-WFQFN Exposed Pad
- Supplier Device Package: 32-VQFN (5x5)
- Base Part Number: LV882
- detail: Motor Driver Bi-CMOS Parallel, PWM 32-VQFN (5x5)
