دیتاشیت FW344A-TL-2W
مشخصات دیتاشیت
| نام دیتاشیت |
FW344A
|
| حجم فایل |
451.95
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
9
|
مشخصات
-
Manufacturer:
ON Semiconductor
-
Series:
-
-
Packaging:
Tape & Reel (TR)
-
Part Status:
Obsolete
-
FET Type:
N and P-Channel
-
FET Feature:
Logic Level Gate, 4V Drive
-
Drain to Source Voltage (Vdss):
30V
-
Current - Continuous Drain (Id) @ 25°C:
4.5A, 3.5A
-
Rds On (Max) @ Id, Vgs:
64mOhm @ 4.5A, 10V
-
Vgs(th) (Max) @ Id:
-
-
Gate Charge (Qg) (Max) @ Vgs:
5.6nC @ 10V
-
Input Capacitance (Ciss) (Max) @ Vds:
280pF @ 10V
-
Power - Max:
1.7W
-
Operating Temperature:
150°C (TJ)
-
Mounting Type:
Surface Mount
-
Package / Case:
8-SOIC (0.154", 3.90mm Width)
-
Supplier Device Package:
8-SOIC
-
Base Part Number:
FW344
-
detail:
Mosfet Array N and P-Channel 30V 4.5A, 3.5A 1.7W Surface Mount 8-SOIC
