دیتاشیت MCH3374-TL-W

MCH3374

مشخصات دیتاشیت

نام دیتاشیت MCH3374
حجم فایل 577.24 کیلوبایت
نوع فایل pdf
تعداد صفحات 5

دانلود دیتاشیت MCH3374

MCH3374 Datasheet

مشخصات

  • Manufacturer: ON Semiconductor
  • Series: -
  • Packaging: Cut Tape (CT)
  • Part Status: Obsolete
  • FET Type: P-Channel
  • Technology: MOSFET (Metal Oxide)
  • Drain to Source Voltage (Vdss): 12V
  • Current - Continuous Drain (Id) @ 25°C: 3A (Ta)
  • Drive Voltage (Max Rds On, Min Rds On): 1.8V, 4V
  • Rds On (Max) @ Id, Vgs: 70mOhm @ 1.5A, 4.5V
  • Vgs(th) (Max) @ Id: 1.4V @ 1mA
  • Gate Charge (Qg) (Max) @ Vgs: 5.6nC @ 4.5V
  • Vgs (Max): ±8V
  • Input Capacitance (Ciss) (Max) @ Vds: 405pF @ 6V
  • FET Feature: -
  • Power Dissipation (Max): 1W (Ta)
  • Operating Temperature: 150°C (TJ)
  • Mounting Type: Surface Mount
  • Supplier Device Package: SC-70FL/MCPH3
  • Package / Case: 3-SMD, Flat Lead
  • Base Part Number: MCH33
  • detail: P-Channel 12V 3A (Ta) 1W (Ta) Surface Mount SC-70FL/MCPH3
