دیتاشیت MCH6344-TL-W

MCH6344

مشخصات دیتاشیت

نام دیتاشیت MCH6344
حجم فایل 684.422 کیلوبایت
نوع فایل pdf
تعداد صفحات 5

دانلود دیتاشیت MCH6344

MCH6344 Datasheet

مشخصات

  • Manufacturer: ON Semiconductor
  • Series: -
  • Packaging: Cut Tape (CT)
  • Part Status: Obsolete
  • FET Type: P-Channel
  • Technology: MOSFET (Metal Oxide)
  • Drain to Source Voltage (Vdss): 30V
  • Current - Continuous Drain (Id) @ 25°C: 2A (Ta)
  • Drive Voltage (Max Rds On, Min Rds On): 4V, 10V
  • Rds On (Max) @ Id, Vgs: 150mOhm @ 1A, 10V
  • Vgs(th) (Max) @ Id: 2.6V @ 1mA
  • Gate Charge (Qg) (Max) @ Vgs: 3.9nC @ 10V
  • Vgs (Max): ±20V
  • Input Capacitance (Ciss) (Max) @ Vds: 172pF @ 10V
  • FET Feature: -
  • Power Dissipation (Max): 800mW (Ta)
  • Operating Temperature: 150°C (TJ)
  • Mounting Type: Surface Mount
  • Supplier Device Package: SC-88FL/MCPH6
  • Package / Case: 6-SMD, Flat Leads
  • Base Part Number: MCH63
  • detail: P-Channel 30V 2A (Ta) 800mW (Ta) Surface Mount SC-88FL/MCPH6
