NGTD15R65F2WP دیتاشیت

NGTD15R65F2WP

مشخصات دیتاشیت

نام دیتاشیت NGTD15R65F2WP
حجم فایل 71.957 کیلوبایت
نوع فایل pdf
تعداد صفحات 3

مشاهده دیتاشیت NGTD15R65F2WP

دانلود دیتاشیت

سایر مستندات

NGTD15R65F2 3 pages

مشخصات فنی

  • RoHS: true
  • Category: Diodes/Switching Diode
  • Datasheet: onsemi NGTD15R65F2WP
  • Power Dissipation: -
  • Diode Configuration: Single
  • Reverse Voltage (Vr): 650V
  • Operating Temperature: +175°C@(Tj)
  • Forward Voltage (Vf@If): 2.2V@75A
  • Reverse Leakage Current: -
  • Reverse Recovery Time (trr): -
  • Average Rectified Current (Io): -
  • Package: SMD
  • Manufacturer: onsemi
  • Series: -
  • Packaging: Bulk
  • Part Status: Active
  • Diode Type: Standard
  • Voltage - DC Reverse (Vr) (Max): 650V
  • Current - Average Rectified (Io): -
  • Voltage - Forward (Vf) (Max) @ If: 2.9V @ 25A
  • Speed: -
  • Current - Reverse Leakage @ Vr: 1µA @ 650V
  • Capacitance @ Vr, F: -
  • Mounting Type: Surface Mount
  • Package / Case: Die
  • Supplier Device Package: Die
  • Operating Temperature - Junction: 175°C (Max)
  • Base Part Number: NGTD15
  • detail: Diode Standard 650V Surface Mount Die
