FDWS9420-F085 دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
FDWS9420_F085
|
|
حجم فایل
|
596.52
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
7
|
مشخصات فنی
-
Manufacturer:
ON Semiconductor
-
Series:
-
-
Packaging:
Tape & Reel (TR)
-
Part Status:
Obsolete
-
FET Type:
2 N-Channel (Dual)
-
FET Feature:
Standard
-
Drain to Source Voltage (Vdss):
40V
-
Current - Continuous Drain (Id) @ 25°C:
20A (Tc)
-
Rds On (Max) @ Id, Vgs:
5.8mOhm @ 20A, 10V
-
Vgs(th) (Max) @ Id:
4V @ 250µA
-
Gate Charge (Qg) (Max) @ Vgs:
43nC @ 10V
-
Input Capacitance (Ciss) (Max) @ Vds:
2100pF @ 20V
-
Power - Max:
75W
-
Operating Temperature:
-55°C ~ 175°C (TJ)
-
Mounting Type:
Surface Mount
-
Package / Case:
8-PowerTDFN
-
Supplier Device Package:
8-PQFN (5x6)
-
Base Part Number:
FDWS9
-
detail:
Mosfet Array 2 N-Channel (Dual) 40V 20A (Tc) 75W Surface Mount 8-PQFN (5x6)
