دیتاشیت NVD4810NT4G-TB01

مشخصات دیتاشیت

دانلود دیتاشیت NTD4810N, NVD4810N	NTD4810N, NVD4810N Datasheet

Manufacturer: ON Semiconductor
Series: Automotive, AEC-Q101
Packaging: Tape & Reel (TR)
Part Status: Obsolete
FET Type: N-Channel
Technology: MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss): 30V
Current - Continuous Drain (Id) @ 25°C: 9A (Ta), 54A (Tc)
Drive Voltage (Max Rds On, Min Rds On): 4.5V, 10V
Rds On (Max) @ Id, Vgs: 10mOhm @ 30A, 10V
Vgs(th) (Max) @ Id: 2.5V @ 250µA
Gate Charge (Qg) (Max) @ Vgs: 21nC @ 11.5V
Vgs (Max): ±20V
Input Capacitance (Ciss) (Max) @ Vds: 1350pF @ 12V
FET Feature: -
Power Dissipation (Max): 1.4W (Ta), 50W (Tc)
Operating Temperature: -55°C ~ 175°C (TJ)
Mounting Type: Surface Mount
Supplier Device Package: DPAK-3
Package / Case: TO-252-3, DPak (2 Leads + Tab), SC-63
Base Part Number: NVD481
detail: N-Channel 30V 9A (Ta), 54A (Tc) 1.4W (Ta), 50W (Tc) Surface Mount DPAK-3
