دیتاشیت NVD5802NT4G-TB01

مشخصات دیتاشیت

دانلود دیتاشیت NTD5802N, NVD5802N	NTD5802N, NVD5802N Datasheet

Manufacturer: ON Semiconductor
Series: Automotive, AEC-Q101
Packaging: Tape & Reel (TR)
Part Status: Obsolete
FET Type: N-Channel
Technology: MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss): 40V
Current - Continuous Drain (Id) @ 25°C: 16.4A (Ta), 101A (Tc)
Drive Voltage (Max Rds On, Min Rds On): 5V, 10V
Rds On (Max) @ Id, Vgs: 4.4mOhm @ 50A, 10V
Vgs(th) (Max) @ Id: 3.5V @ 250µA
Gate Charge (Qg) (Max) @ Vgs: 100nC @ 10V
Vgs (Max): ±20V
Input Capacitance (Ciss) (Max) @ Vds: 5300pF @ 12V
FET Feature: -
Power Dissipation (Max): 2.5W (Ta), 93.75W (Tc)
Operating Temperature: -55°C ~ 175°C (TJ)
Mounting Type: Surface Mount
Supplier Device Package: DPAK
Package / Case: TO-252-3, DPak (2 Leads + Tab), SC-63
Base Part Number: NVD580
detail: N-Channel 40V 16.4A (Ta), 101A (Tc) 2.5W (Ta), 93.75W (Tc) Surface Mount DPAK
