دیتاشیت FDS8449-F085P

FDS8449-F085

مشخصات دیتاشیت

نام دیتاشیت FDS8449-F085
حجم فایل 525.636 کیلوبایت
نوع فایل pdf
تعداد صفحات 6

دانلود دیتاشیت FDS8449-F085

FDS8449-F085 Datasheet

مشخصات

  • Manufacturer: ON Semiconductor
  • Series: Automotive, AEC-Q101, PowerTrench®
  • Packaging: Tape & Reel (TR)
  • Part Status: Obsolete
  • FET Type: N-Channel
  • Technology: MOSFET (Metal Oxide)
  • Drain to Source Voltage (Vdss): 40V
  • Current - Continuous Drain (Id) @ 25°C: 7.6A (Ta)
  • Drive Voltage (Max Rds On, Min Rds On): 4.5V, 10V
  • Rds On (Max) @ Id, Vgs: 29mOhm @ 7.6A, 10V
  • Vgs(th) (Max) @ Id: 3V @ 250µA
  • Gate Charge (Qg) (Max) @ Vgs: 11nC @ 5V
  • Vgs (Max): ±20V
  • Input Capacitance (Ciss) (Max) @ Vds: 760pF @ 20V
  • FET Feature: -
  • Power Dissipation (Max): 5W (Ta)
  • Operating Temperature: -55°C ~ 150°C (TJ)
  • Mounting Type: Surface Mount
  • Supplier Device Package: 8-SOIC
  • Package / Case: 8-SOIC (0.154", 3.90mm Width)
  • Base Part Number: FDS84
  • detail: N-Channel 40V 7.6A (Ta) 5W (Ta) Surface Mount 8-SOIC
