ESDR7534W1T2G دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
ESDR7534
|
|
حجم فایل
|
66.315
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
5
|
مشخصات فنی
-
Manufacturer:
ON Semiconductor
-
Series:
-
-
Packaging:
Cut Tape (CT)
-
Part Status:
Obsolete
-
Type:
Steering (Rail to Rail)
-
Unidirectional Channels:
4
-
Voltage - Reverse Standoff (Typ):
5V (Max)
-
Voltage - Breakdown (Min):
6V
-
Voltage - Clamping (Max) @ Ipp:
30V
-
Current - Peak Pulse (10/1000µs):
-
-
Power - Peak Pulse:
-
-
Power Line Protection:
Yes
-
Applications:
General Purpose
-
Capacitance @ Frequency:
1.9pF @ 1MHz
-
Operating Temperature:
-55°C ~ 125°C (TJ)
-
Mounting Type:
Surface Mount
-
Package / Case:
6-TSSOP, SC-88, SOT-363
-
Supplier Device Package:
SC-88/SC70-6/SOT-363
-
Base Part Number:
ESDR75
-
detail:
30V Clamp Ipp Tvs Diode Surface Mount SC-88/SC70-6/SOT-363
