دیتاشیت NTA4153NT1G
مشخصات دیتاشیت
| نام دیتاشیت |
Nxx4153N
|
| حجم فایل |
130.95
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
6
|
مشخصات
-
RoHS:
true
-
Type:
N Channel
-
Category:
Triode/MOS Tube/Transistor/MOSFETs
-
Datasheet:
onsemi NTA4153NT1G
-
Operating Temperature:
-55°C~+150°C@(Tj)
-
Power Dissipation (Pd):
300mW
-
Total Gate Charge (Qg@Vgs):
1.82nC@4.5V
-
Drain Source Voltage (Vdss):
20V
-
Input Capacitance (Ciss@Vds):
110pF@16V
-
Continuous Drain Current (Id):
915mA
-
Gate Threshold Voltage (Vgs(th)@Id):
1.1V@250uA
-
Drain Source On Resistance (RDS(on)@Vgs,Id):
230mΩ@4.5V,600mA
-
Package:
SOT-523(SC-75)
-
Manufacturer:
onsemi
-
Series:
-
-
Packaging:
Cut Tape (CT)
-
Part Status:
Active
-
FET Type:
N-Channel
-
Technology:
MOSFET (Metal Oxide)
-
Drain to Source Voltage (Vdss):
20V
-
Current - Continuous Drain (Id) @ 25°C:
915mA (Ta)
-
Drive Voltage (Max Rds On, Min Rds On):
1.5V, 4.5V
-
Rds On (Max) @ Id, Vgs:
230mOhm @ 600mA, 4.5V
-
Vgs(th) (Max) @ Id:
1.1V @ 250µA
-
Gate Charge (Qg) (Max) @ Vgs:
1.82nC @ 4.5V
-
Vgs (Max):
±6V
-
Input Capacitance (Ciss) (Max) @ Vds:
110pF @ 16V
-
FET Feature:
-
-
Power Dissipation (Max):
300mW (Tj)
-
Mounting Type:
Surface Mount
-
Supplier Device Package:
SC-75, SOT-416
-
Package / Case:
SC-75, SOT-416
-
Base Part Number:
NTA41
-
detail:
N-Channel 20V 915mA (Ta) 300mW (Tj) Surface Mount SC-75, SOT-416
