- MP2002 Datasheet
MP2002DD-LF-P Datasheet
Datasheet specifications
| Datasheet's name | MP2002 Datasheet |
|---|---|
| File size | 353.385 KB |
| File type | |
| Number of pages | 11 |
Download Datasheet MP2002 Datasheet |
Download Datasheet |
|---|
Other documentations
No other documentation was found!
Technical specifications
- Manufacturer: Monolithic Power Systems Inc.
- Series: -
- Packaging: Cut Tape (CT)
- Part Status: Discontinued at Digi-Key
- Output Configuration: Positive
- Output Type: Adjustable
- Number of Regulators: 1
- Voltage - Input (Max): 6.5V
- Voltage - Output (Min/Fixed): 0.5V
- Voltage - Output (Max): 5V
- Voltage Dropout (Max): 0.29V @ 500mA (Typ)
- Current - Output: 500mA
- Current - Quiescent (Iq): 100µA
- Current - Supply (Max): 5mA
- PSRR: -
- Control Features: Enable, Power Good
- Protection Features: Over Current, Over Temperature
- Operating Temperature: -40°C ~ 125°C
- Mounting Type: Surface Mount
- Package / Case: 8-TFDFN Exposed Pad
- Supplier Device Package: 8-QFN (2x3)
- detail: Linear Voltage Regulator IC 1 Output 500mA 8-QFN (2x3)
