MPQ3426DL-AEC1-LF-Z Datasheet
Datasheet specifications
| Datasheet's name | MPQ3426 |
|---|---|
| File size | 555.382 KB |
| File type | |
| Number of pages | 17 |
Download Datasheet MPQ3426 |
Download Datasheet |
|---|
Other documentations
No other documentation was found!
Technical specifications
- Manufacturer: Monolithic Power Systems Inc.
- Series: Automotive, AEC-Q100
- Packaging: Cut Tape (CT)
- Part Status: Active
- Function: Step-Up
- Output Configuration: Positive
- Topology: Boost
- Output Type: Programmable
- Number of Outputs: 1
- Voltage - Input (Min): 3.2V
- Voltage - Input (Max): 22V
- Voltage - Output (Min/Fixed): 3.2V
- Voltage - Output (Max): 35V
- Current - Output: 6A
- Frequency - Switching: 300kHz ~ 2MHz
- Synchronous Rectifier: No
- Operating Temperature: -40°C ~ 125°C (TJ)
- Mounting Type: Surface Mount
- Package / Case: 14-VFDFN Exposed Pad
- Supplier Device Package: 14-QFN (3x4)
- detail: Boost Switching Regulator IC Positive Programmable 3.2V 1 Output 6A 14-VFDFN Exposed Pad
