دیتاشیت MP2315 Datasheet

مشخصات دیتاشیت

MP2315 Datasheet	دانلود دیتاشیت

مستندات دیگری یافت نشد!

Manufacturer: Monolithic Power Systems Inc.
Series: -
Packaging: Cut Tape (CT)
Part Status: Not For New Designs
Function: Step-Down
Output Configuration: Positive
Topology: Buck
Output Type: Adjustable
Number of Outputs: 1
Voltage - Input (Min): 4.5V
Voltage - Input (Max): 24V
Voltage - Output (Min/Fixed): 0.8V
Voltage - Output (Max): 22.8V
Current - Output: 3A
Frequency - Switching: 500kHz
Synchronous Rectifier: Yes
Operating Temperature: -40°C ~ 125°C (TJ)
Mounting Type: Surface Mount
Package / Case: SOT-23-8 Thin, TSOT-23-8
Supplier Device Package: TSOT-23-8
detail: Buck Switching Regulator IC Positive Adjustable 0.8V 1 Output 3A SOT-23-8 Thin, TSOT-23-8
