دیتاشیت MP2013AGJE-5-C672-Z

MP2013A

مشخصات دیتاشیت

نام دیتاشیت MP2013A
حجم فایل 120.675 کیلوبایت
نوع فایل pdf
تعداد صفحات 1

دانلود دیتاشیت MP2013A

MP2013A Datasheet

مشخصات

  • Manufacturer: Monolithic Power Systems Inc.
  • Series: -
  • Packaging: Tape & Reel (TR)
  • Part Status: Active
  • Output Configuration: Positive
  • Output Type: Fixed
  • Number of Regulators: 1
  • Voltage - Input (Max): 40V
  • Voltage - Output (Min/Fixed): 5V
  • Voltage - Output (Max): -
  • Voltage Dropout (Max): 0.85V @ 150mA
  • Current - Output: 150mA
  • Current - Quiescent (Iq): 8µA
  • Current - Supply (Max): 48µA
  • PSRR: 58dB ~ 41dB (100Hz ~ 1kHz)
  • Control Features: Enable
  • Protection Features: Over Current, Over Temperature
  • Operating Temperature: -40°C ~ 125°C (TJ)
  • Mounting Type: Surface Mount
  • Package / Case: SOT-23-4 Thin, TSOT-23-4
  • Supplier Device Package: TSOT-23-4
  • detail: Linear Voltage Regulator IC 1 Output 150mA TSOT-23-4
