دیتاشیت MPQ8636GV-20-Z
مشخصات دیتاشیت
نام دیتاشیت | MPQ8636(H)GV-20 Datasheet |
---|---|
حجم فایل | 732.489 کیلوبایت |
نوع فایل | |
تعداد صفحات | 24 |
دانلود دیتاشیت MPQ8636(H)GV-20 Datasheet |
MPQ8636(H)GV-20 Datasheet Datasheet |
---|
مشخصات
- Manufacturer: Monolithic Power Systems Inc.
- Series: -
- Packaging: Tape & Reel (TR)
- Part Status: Not For New Designs
- Function: Step-Down
- Output Configuration: Positive
- Topology: Buck
- Output Type: Adjustable
- Number of Outputs: 1
- Voltage - Input (Min): 4.5V
- Voltage - Input (Max): 18V
- Voltage - Output (Min/Fixed): 0.611V
- Voltage - Output (Max): 13V
- Current - Output: 20A
- Frequency - Switching: 200kHz ~ 1MHz
- Synchronous Rectifier: Yes
- Operating Temperature: -40°C ~ 125°C (TJ)
- Mounting Type: Surface Mount
- Package / Case: 25-VFQFN
- Supplier Device Package: 25-QFN (5x4)
- detail: Buck Switching Regulator IC Positive Adjustable 0.611V 1 Output 20A 25-VFQFN
