دیتاشیت MPQ18021HS-A-LF-Z
مشخصات دیتاشیت
نام دیتاشیت | MPQ18021-A Datasheet |
---|---|
حجم فایل | 484.284 کیلوبایت |
نوع فایل | |
تعداد صفحات | 12 |
دانلود دیتاشیت MPQ18021-A Datasheet |
MPQ18021-A Datasheet Datasheet |
---|
مشخصات
- Manufacturer: Monolithic Power Systems Inc.
- Series: -
- Packaging: Tube
- Part Status: Active
- Driven Configuration: Half-Bridge
- Channel Type: Independent
- Number of Drivers: 2
- Gate Type: N-Channel MOSFET
- Voltage - Supply: 9V ~ 18V
- Logic Voltage - VIL, VIH: 1V, 2.4V
- Current - Peak Output (Source, Sink): 2.5A, 2.5A
- Input Type: Non-Inverting
- High Side Voltage - Max (Bootstrap): 115V
- Rise / Fall Time (Typ): 12ns, 9ns
- Operating Temperature: -40°C ~ 125°C (TJ)
- Mounting Type: Surface Mount
- Package / Case: 8-SOIC (0.154", 3.90mm Width)
- Supplier Device Package: 8-SOIC
- detail: Half-Bridge Gate Driver IC Non-Inverting 8-SOIC
