- MP2212 Datasheet
MP2212DN-LF-Z Datasheet
Datasheet specifications
| Datasheet's name | MP2212 Datasheet |
|---|---|
| File size | 709.995 KB |
| File type | |
| Number of pages | 14 |
Download Datasheet MP2212 Datasheet |
Download Datasheet |
|---|
Other documentations
No other documentation was found!
Technical specifications
- Manufacturer: Monolithic Power Systems Inc.
- Series: -
- Packaging: Tube
- Part Status: Active
- Function: Step-Down
- Output Configuration: Positive
- Topology: Buck
- Output Type: Adjustable
- Number of Outputs: 1
- Voltage - Input (Min): 3V
- Voltage - Input (Max): 16V
- Voltage - Output (Min/Fixed): 0.8V
- Voltage - Output (Max): 14.4V
- Current - Output: 3A
- Frequency - Switching: 600kHz
- Synchronous Rectifier: Yes
- Operating Temperature: -40°C ~ 85°C (TA)
- Mounting Type: Surface Mount
- Package / Case: 8-SOIC (0.154", 3.90mm Width) Exposed Pad
- Supplier Device Package: 8-SOICE
- detail: Buck Switching Regulator IC Positive Adjustable 0.8V 1 Output 3A 8-SOIC (0.154", 3.90mm Width) Exposed Pad
