MEZDPD1620A-84E3 数据手册
其他文档
未找到其他文档！
技术规格
- Manufacturer: Monolithic Power Systems Inc.
- Series: MEZDPD1620
- Part Status: Active
- Type: Non-Isolated PoL Module
- Number of Outputs: 1
- Voltage - Input (Min): 4V
- Voltage - Input (Max): 10V
- Voltage - Output 1: 1.2V
- Voltage - Output 2: -
- Voltage - Output 3: -
- Voltage - Output 4: -
- Current - Output (Max): 20A
- Applications: ITE (Commercial)
- Features: -
- Operating Temperature: -
- Efficiency: 96%
- Mounting Type: Through Hole
- Package / Case: 18-DIP Module
- Size / Dimension: 0.91" L x 0.63" W x 0.56" H (23.0mm x 16.0mm x 14.1mm)
- Supplier Device Package: -
- Control Features: -
- Approval Agency: -
- detail: Non-Isolated PoL Module DC DC Converter 1 Output 1.2V 20A 4V - 10V Input
