DSI30-12AS-TRL 数据手册
其他文档
未找到其他文档！
技术规格
- Manufacturer: IXYS
- Series: -
- Packaging: Cut Tape (CT)
- Part Status: Active
- Diode Type: Standard
- Voltage - DC Reverse (Vr) (Max): 1200V
- Current - Average Rectified (Io): 30A
- Voltage - Forward (Vf) (Max) @ If: 1.29V @ 30A
- Speed: Standard Recovery >500ns, > 200mA (Io)
- Current - Reverse Leakage @ Vr: 40µA @ 1200V
- Capacitance @ Vr, F: 10pF @ 400V, 1MHz
- Mounting Type: Surface Mount
- Package / Case: TO-263-3, D²Pak (2 Leads + Tab), TO-263AB
- Supplier Device Package: TO-263AB (D²PAK)
- Operating Temperature - Junction: -40°C ~ 175°C
- Base Part Number: DSI30-12
- detail: Diode Standard 1200V 30A Surface Mount TO-263AB (D²PAK)
