دیتاشیت IXFH50N20

IXF(H,M,T)(42,50,58)N20

مشخصات دیتاشیت

نام دیتاشیت IXF(H,M,T)(42,50,58)N20
حجم فایل 695.026 کیلوبایت
نوع فایل pdf
تعداد صفحات 5

دانلود دیتاشیت IXF(H,M,T)(42,50,58)N20

IXF(H,M,T)(42,50,58)N20 Datasheet

مشخصات

  • Manufacturer: IXYS
  • Series: HiPerFET™
  • Packaging: Tube
  • Part Status: Not For New Designs
  • FET Type: N-Channel
  • Technology: MOSFET (Metal Oxide)
  • Drain to Source Voltage (Vdss): 200V
  • Current - Continuous Drain (Id) @ 25°C: 50A (Tc)
  • Drive Voltage (Max Rds On, Min Rds On): 10V
  • Rds On (Max) @ Id, Vgs: 45mOhm @ 25A, 10V
  • Vgs(th) (Max) @ Id: 4V @ 4mA
  • Gate Charge (Qg) (Max) @ Vgs: 220nC @ 10V
  • Vgs (Max): ±20V
  • Input Capacitance (Ciss) (Max) @ Vds: 4400pF @ 25V
  • FET Feature: -
  • Power Dissipation (Max): 300W (Tc)
  • Operating Temperature: -55°C ~ 150°C (TJ)
  • Mounting Type: Through Hole
  • Supplier Device Package: TO-247AD (IXFH)
  • Package / Case: TO-247-3
  • detail: N-Channel 200V 50A (Tc) 300W (Tc) Through Hole TO-247AD (IXFH)
